Medium-heavy Plate Welding Application
Technology Features
l The high stability of the CRP robot is the basis for thick plate welding; l Weaving welding + multi-form point finding + arc tracking are the basic functions of medium and thick plate welding.
l The functions of these arc welding software packages of CRP robots have a large number of market applications and their stability has been affirmed; l Stable weaving welding can effectively increase the weld width; Various forms of positioning are used to accurately search the starting point and end of various welds, adapting to the deviation of the workpiece. l Using arc tracking in the welding process to correct the deviation of the weld due to deformation or workpiece deviation.
l Multi-layer multi-channel software can quickly and flexibly realize multi-layer multi-channel programming.
500A water-cooled hollow welding torch, supporting long-term high-current welding; (if you need the wire positioning function, please choose the wire-clamping water-cooled welding gun).
l The robot and the welding machine communicate through all-digital communication, which is fast and stable. l Single/double pulse weldder, if mixed gas can be used to achieve low spatter welding in the full current range with short arc pulse technology, the welding speed is faster; with high-frequency pulse energy control, the penetration is deeper, the heat input is low, and the scales are more beautiful; with smooth short-circuit transition technology, uniform welding bead, beautiful shape; wire feeding with encoder feedback is more stable and strong anti-interference. l Built-in positioning function: no need to add positioning board.
Application Range:
l6mm-30mm carbon steel
lwith large deformation during the welding process is optional: point finding, arc tracking
Application Field:
lparts for construction machinery, construction machinery, steel structure, road and bridge, petrochemical machinery, mining machinery and other industries
